Owon Programmable Power Supply SPE6102

SKU :
Type : NEW

Pickup available at Intextec

Usually ready in 24 hours

Core Output Characteristics

  • Output Channels: 1 (Single channel)

  • Output Voltage Range: 0 - 60 V

  • Output Current Range: 0 - 10 A

  • Maximum Output Power: 600 W (60V × 10A)

  • Power Type: Switching topology (high efficiency, compact size)

  • Cooling: Temperature-controlled variable-speed fan

  • Load Regulation: ≤ 0.01% + 3 mV (Voltage), ≤ 0.1% + 6 mA (Current)

  • Line Regulation: ≤ 0.01% + 3 mV (Voltage), ≤ 0.1% + 6 mA (Current)

Performance & Accuracy

  • Voltage Readback Accuracy: ±(0.03% + 10 mV)

  • Current Readback Accuracy: ±(0.1% + 10 mA)

  • Voltage Setting Resolution: 1 mV

  • Current Setting Resolution: 1 mA

  • Voltage Readback Resolution: 0.1 mV

  • Current Readback Resolution: 0.1 mA

  • Ripple & Noise (20Hz-20MHz):

    • CV Mode: ≤ 15 mVrms / 50 mVpp

    • CC Mode: ≤ 30 mArms

  • Transient Response Time (to within 1%): ≤ 50 ms (for 50% load change)

  • Efficiency: > 85% (typical)

Programming & Control Features

  1. Operation Modes:

    • Constant Voltage (CV)

    • Constant Current (CC)

    • Automatic CV/CC crossover

  2. Programming Functions:

    • Voltage/Current Sweep:

      • Linear and logarithmic sweeps

      • Programmable start/stop values

      • Adjustable step size and dwell time

    • Sequence Programming:

      • Up to 100 sequence steps

      • Each step programmable for voltage, current, and duration (1ms to 99999s)

      • Loop/repeat function for sequences

    • Timed Output:

      • Programmable ON/OFF duration

      • Countdown timer display

  3. Memory System:

    • 10 front-panel memories (quick recall)

    • Internal non-volatile storage for sequences

    • Save/load configurations via USB

  4. Measurement Features:

    • Real-time voltage, current, power display

    • Data logging capability (timestamps)

    • Max/Min/Avg value recording

    • Relative measurement (zero offset)

Protection & Safety Features

  • OVP (Over Voltage Protection): User-programmable limit (0.1V to max)

  • OCP (Over Current Protection): User-programmable limit (1mA to max)

  • OPP (Over Power Protection): User-programmable limit (0.1W to max)

  • OTP (Over Temperature Protection): Automatic thermal shutdown

  • Input Undervoltage Protection: Prevents operation at low input voltage

  • Output Reverse Polarity Protection: For external voltage backfeed

  • Short Circuit Protection: Auto current limiting with auto-recovery

  • Fan Fault Detection: Warns on cooling system failure

Display & Interface

  • Display Type: 4.3-inch TFT color LCD

  • Display Information:

    • Primary: Voltage, Current, Power

    • Secondary: OVP/OCP/OPP settings, timer, mode status

    • Graphic: Real-time waveform display of V/I

  • Front Panel Controls:

    • Rotary encoder with push function

    • Dedicated numeric keypad

    • Function soft keys

    • OUTPUT on/off button with indicator

  • Output Terminals:

    • High-current binding posts (red/black)

    • Earth ground terminal

    • Remote sense terminals (compensates for lead voltage drop)

Communication Interfaces

  • USB Device Port: USB 2.0 Type-B for PC connection

  • USB Host Port: USB Type-A for memory stick (save/load configurations)

  • Ethernet: 10/100 Mbps LAN port (RJ-45)

  • RS-232/485: Serial communication port (DB-9)

  • Digital I/O: Trigger input/output (BNC connector)

  • Remote Sensing: Dedicated terminals for 4-wire measurement

Remote Control & Programming

  • Command Set: SCPI (Standard Commands for Programmable Instruments) compatible

  • Communication Protocols:

    • USB-TMC (Test & Measurement Class)

    • TCP/IP Socket (Ethernet)

    • VXI-11 (LAN)

    • Modbus RTU (RS-485)

  • Software Support:

    • Owon PSU Manager (Windows)

    • LabVIEW drivers available

    • Python examples (PyVISA)

    • Web browser interface (via Ethernet)

Physical Specifications

  • Dimensions (W×H×D): 260 × 155 × 420 mm (10.2 × 6.1 × 16.5 inches)

  • Weight: 8.5 kg (18.7 lbs)

  • AC Input:

    • Voltage: 110-240 VAC ±10%

    • Frequency: 47-63 Hz

    • Power Consumption: ≤ 800 VA (max)

  • Operating Temperature: 0°C to 40°C (32°F to 104°F)

  • Storage Temperature: -20°C to 70°C (-4°F to 158°F)

  • Humidity: ≤ 80% RH (non-condensing)

  • Altitude: Up to 2000 meters

  • Cooling: Forced air (front-to-back airflow)

Package Contents

  • Owon SPE6102 Power Supply Unit

  • Power cord (IEC C13)

  • Test leads with alligator clips

  • USB cable (Type A to Type B)

  • Quick start guide

  • Certificate of calibration

  • Rack mount ears (optional/separate)

Safety & Compliance

  • Safety Standards: IEC 61010-1, UL 61010-1

  • EMC Standards: EN 61326-1

  • RoHS: Compliant

  • CE Mark: Yes

  • Warranty: 3 years standard

Typical Applications

  1. Automated Test Equipment (ATE): Production line testing

  2. R&D Laboratories: Device characterization, burn-in testing

  3. Battery Testing: Charge/discharge profiling

  4. LED Testing: Constant current driver testing

  5. Educational Institutions: Advanced electronics labs

  6. Service Centers: Repair and calibration

Key Advantages of SPE6102

  • High Power Density: 600W in compact 2U form factor

  • Excellent Programmability: 100-step sequences for complex tests

  • Multiple Interfaces: USB, LAN, RS-232/485 for flexible integration

  • Remote Sensing: Compensates for cable voltage drop

  • Comprehensive Protection: User-settable OVP/OCP/OPP

  • Color Display: Intuitive visualization of measurements
